NEW SuperMicro F627R3-R72B+ 4U FatTwin Server 4-Node X9DRFR 8x LGA2011 E5-2600v2
89045NEW SuperMicro F627R3-R72B+ 4U FatTwin Server 4-Node X9DRFR 8x LGA2011 E5-2600v2
NEW SuperMicro F627R3-R72B+ 4U FatTwin Server 4-Node X9DRFR 8x LGA2011 E5-2600v2
NEW SuperMicro F627R3-R72B+ 4U FatTwin Server 4-Node X9DRFR 8x LGA2011 E5-2600v2
BAREBONE/CTO, NO MEMORY, NO CPUs, NO HDDs installed.
The unit is brand new, never deployed, comes in an original box with all the accessories included.
Specifications:
| Form Factor | 4U Rackmount |
|---|---|
| Model | SUPERMICRO F627R3-R72B+ |
| Processor(s) | Intel® Xeon® processor E5-2600 and E5-2600 v2 family† (up to 135W TDP; 130W TDP up to 47°C *) Dual Socket R (LGA 2011) |
| Memory | 16x 240-pin DDR3 DIMM slots Up to 1TB DDR3 ECC LRDIMM Up to 512GB DDR3 ECC Registered memory (RDIMM) Up to 128GB DDR3 ECC Un-Buffered memory (UDIMM) |
| # of DIMMs and Capacity |
1866/1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs 32GB, 16GB, 8GB, 4GB, 2GB, 1GB |
| Hard Drives | 6+2 3.5" Hot-swap SAS2 HDD Bays via Broadcom 2208 |
| RAID Controller | SAS2 via Broadcom 2208 |
| RAID Levels | HW RAID 0, 1, 5, 6, 10, 50, 60 support |
| Power Supply | 4x 1280W |
| Optical Drive | N/A |
| Network | Intel® i350 Dual Port Gigabit Ethernet Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI) |
| Remote Access | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC |
| Rackmount Rails | YES |
| Operating System | N/A |
| Power Cord | YES |
Condition:The unit is brand new, never deployed, comes in an original box with all the accessories included.
30-Day Warranty!
