ATTO FC164E Celerity Quad Channel 16GB/s Fibre Channel Gen 5 PCIe 3.0 x8 HBA Host Bus Adapter

ATTO Celerity FC-164E Model P/N: CTFC-164E-000

Transceiver: Not included

Mounting bracket: Full Height

Condition: Clean, tested pull - Guaranteed 100% working!

No software, cables or other accessories included.

30-Day Warranty!

Manufacturer's description and specifications:

The ATTO Celerity FC-164E leverages two next-generation storage technologies – PCIe 3.0 interconnect and 16-Gigabit Fibre Channel to provide an advanced storage connectivity solution with high performance, intelligence and scalability. Celerity FC-164E 16Gb/s quad-channel HBAs deliver up to 6400 MB/s in a single PCIe slot solution, allowing original equipment manufacturers and system integrators to design state-of-the-art data infrastructures. The FC-164E is well-suited for the needs of Linux and Windows platforms operating in high performance computing, virtualization, and other high IOP environments typically found in enterprise data centers.

Advanced Data Streaming (ADS) Latency-management technology that controls the acceleration of data transfers to move large amounts of data faster and more efficiently.

Key Features

• Auto Negotiation to 16Gb, 8Gb and 4Gb devices
• 3200MB/s throughput per port in full-duplex mode
• Supports arbitrated loop, point-to-point and direct fabric/switch attach
• ANSI Fibre Channel: FC-FS, FCP, FC-AL, FC-AL2, FC-PLDA, FC-FLA
• Flash ROM for easy field upgrades
• FC Class 3 Support
• Buffer Credits: 41
• Software RAID support with ATTO’s Power Center software
• Pluggable optical LC SFP+
• Initiator and target mode (OEM) support
• Supports FDMI and WMI
• Supports NPIV and Virtual Fabric
• Supports Thunderbolt

User Benefits

• Superior performance for enterprise applications
• Increased switch port availability
• Reduced cost per MB of data transferred
• Seamless integration into existing FC SANs
• Extensive certification with SAN infrastructure components
• Support for virtualized server environments

Management Tools

• ATTO Config Tool (w/GUI) BIOS-based management and configuration utility

Bus Specifications

• x8 PCI Express 3.0 host interface
• Supports PCI Express Base Spec 3.0
• Supports PCI Express CEM Spec 3.0
• PCI Hot Plug spec 1.0

External Connectivity

• Standard size brackets installed
• Quad (4) pluggable 16Gb optical LC SFP+ modules (not included)
• External LEDs for on-line and speed status for each port

Operating System Support

• Windows Server 2003, 2008, 2008 R2, 2012
• Windows XP, Vista, 7, 8
• Mac OS X 10.6.x & later
• SUSE Linux
• openSUSE Linux
• Red Hat Linux
• VMware ESXi Server® 5.x
• Hyper-V

Compliant Standards

• FCC Class B certified, FCC Part 15 B, RoHS, IEC 60950-1, EN55022:2010, EN 55024:2010

Dimensions

• Length 6.500”, Height 4”

Operating Temperature

• Hardware Environment
  • Temperature: 0-55° C
  • Humidity: 10 - 90% non-condensing
• Operating Voltage (typical)
  • 35.23W
