Dell MGGPJ AMD Xilinx Alveo U200 Accelerator Card 64GB 2-Port 100GbE Passive
94094Dell MGGPJ AMD Xilinx Alveo U200 Accelerator Card 64GB 2-Port 100GbE Passive
Dell MGGPJ AMD Xilinx Alveo U200 Data Center Accelerator Card Passive Cooling PCIe 3.0 x16 64GB 2-Port 100GbE
DELL P/N: MGGPJ
AMD P/N: A-U200-P64G
Thermal Solution: Passive
This Accelerator Card is fanless and designed for servers with high airflow!
Transceiver: Not included
Mounting bracket: Full Height Double Slot
Condition: Clean, tested pull - Guaranteed 100% working!
No software, cables or other accessories included. Comes with Full Height Double Slot mounting bracket only.
30-Day Warranty!
| Thermal cooling solution | Passive |
| Weight | 1066g |
| Form factor | Full height, ¾ length, dual width |
| Total electrical card load 1 | 215W |
| Network interface | 2x QSFP28 |
| PCIe Interface | Gen3 x16 |
| Look-up tables (LUTs) | 1,182K |
| Registers | 2,364K |
| DSP slices | 6,840 |
| UltraRAMs | 960 |
| DDR total capacity | 64 GB |
| DDR maximum data rate | 2400 MT/s |
| DDR total bandwidth | 77 GB/s |
