Supermicro AOC-S3008L-L8i SAS3 12G 8-Port Internal PCI-e x8 3.0 RAID Controller

Supermicro AOC-S3008L-L8i SAS3 12Gbps 8-Port Internal PCI-e 3.0 RAID Controller

Supermicro 12Gb/s Eight-Port SAS Internal RAID Adapter

The Supermicro MegaRAID AOC-S3008L-L8i features 8 internal SAS connectors for high-performance storage connectivity.

Use a Broadcom 3008 I/O processor with Fusion-MPT (Message Passing Technology) for optimum RAID performance and a PCI Express host interface for increased bandwidth, this RAID adapter delivers an intelligent and robust RAID solution.

The AOC-S3008L-L8i supports 63 devices.

• Broadcom 3008 SAS controller
• 8-port (internal), 12Gb/s per port
• Supports 63 devices
• Supports MegaRAID Storage Manager Software
• Automatically negotiates PCI-E (1.x, 2.x AND 3.X) link widths
• Power management support
• Supports 3.0, 6.0, and 12Gb/s SAS and SATA data transfer rates
• Port independent auto-negotiation
• Supports SSP, SMP, STP, and SATA protocols
• Zoning capability w/ SAS2 expanders
• OS Support: Windows 2012, 2k8, Vista, RedHat Enterprise, and SUSE Linux
• Processor at 1.2 GHz
• Supports RAID 0, 1, 1E and 10
• Uses 2 MiniSAS HD (SFF-8643) connectors

Mounting bracket: Full height

Condition: Clean, tested pull - Guaranteed 100% working!

No software, cables or other accessories included. Comes with full height mounting bracket only.

30-Day Warranty!
