Supermicro AS-1014S-WTRT H12SSW-NT 1 Socket SP3 AMD EPYC 7003/7002 1U Server
94941Supermicro AS-1014S-WTRT H12SSW-NT 1 Socket SP3 AMD EPYC 7003/7002 1U Server
Supermicro AS-1014S-WTRT H12SSW-NT Single Socket SP3 AMD EPYC 7003/7002 1U Server Barebone
Barebone unit - sold as pictured. NO CPU/NO RAM, NO HDD.
Rackmount Rail kit, CPU Heatsink, and HDD trays are included. Off-lease equipment. Clean and tested by a qualified technician. Latest BIOS and IPMI installed.
Barebone 1U Rackmount Server Socket SP3 for Single AMD EPYC 7000 Series - Up to 1TB Registered DDR4 2666/2933/3200MHz, 4x Hot-Swap 3.5in drive bays, 4x Sata3 ports (optional 4 U.2 NVMe PCIe 3), 2x 10GbE ports, VGA, IPMI 2.0, 500W 80 Platinum Level Certified Power Supply w/ PMBus - (H12SSW-NT + SC815TS-R504WBP4)
1. Single AMD EPYC 7003/7002 Series Processor (The latest AMD EPYC 7003 Series Processor with AMD 3D V-Cache Technology requires BIOS version 2.3 or newer)
2. 8 DIMMs; up to 2TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM
3. 2 PCI-E 4.0 x16 (FHFL) slots, 1 PCI-E 4.0 x16 (LP) slot
4. Integrated IPMI 2.0 + KVM with dedicated LAN Software Out of Band License key ( SFT-OOB-LIC ) included for OOB BIOS management
5. 4 Hot-swap 3.5" SATA3 drive bays, Optional 4 U.2 NVMe (PCI-E 3.0) drive support via additional kit for NVMe devices
6. 2x 10GBase-T LAN ports via Broadcom BCM57416 Controller
7. 1 VGA, 5 USB 3.0 (4 rear, 1 Type A)
8. 2 SuperDOM (Disk on Module) ports
9. 500W Redundant Power Supplies Platinum Level High-efficiency (Full redundancy based on configuration and application load)
Specifications:
| Form Factor | 1U Rackmount |
|---|---|
| Model | SUPERMICRO AS-1014S-WTRT CSE-815TS-R504WBP4 - 4x 3.5" Bays |
| Processor(s) | Single AMD EPYC 7003/7002 Series Processor (The latest AMD EPYC 7003 Series Processor with AMD 3D V-Cache Technology requires BIOS version 2.3 or newer) Socket SP3 |
| Memory | DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs |
| # of DIMMs and Capacity |
|
| Hard Drives | 4 Hot-swap 3.5" SATA3 drive bays, Optional 4 U.2 NVMe (PCI-E 3.0) drive support via an additional kit for NVMe devices (not included) |
| RAID Controller | Onboard SATA3 controller |
| RAID Levels | N/A |
| Power Supply | 2x 500W PWS-504P-1R |
| Optical Drive | NONE |
| Network | 2x 10GbE LAN Ports via Broadcom BCM57416 1 Realtek RTL8211E PHY (dedicated IPMI) |
| Remote Access | Support for Intelligent Platform Management Interface v. 2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2500 BMC |
| Rackmount Rails | Yes |
| Operating System | N/A |
| Power Cord | NONE |
Condition: Off-lease equipment. Clean and tested by a qualified technician. Latest BIOS and IPMI installed.
