Supermicro CSE-815 4x LFF 2x NVME Slots W/ X10DRD-iNT Server Barebone/CTO

Supermicro CSE-815 4x LFF 2x NVME Slots W/ X10DRD-iNT Server Barebone/CTO

Condition: Off-lease equipment. Clean and tested by a qualified technician. Barebone unit - NO CPU/NO MEMORY/NO HDDs included. SOLD AS PICTURED.

Any Memory/CPUs or other parts purchased at our store can be added/installed and shipped together at no additional cost.

Specifications:

Form Factor 1U Rackmount CSE-815TQ-R500CB Chasis with an optional 4x 3.5" Bays BPN-SAS3-815TQ-N4 SAS3/NVMe Hybrid Backplane
Model SUPERMICRO PIO-618R-TDLR-NV0-LC019
Processor(s)
  • Intel® Xeon® processor E5-2600 v3, Intel® Xeon® processor E5-2600 v4.
  • Dual Socket R3 (LGA 2011) supported, 1 QPI up to 9.6GT/s
Memory
  • 2400?/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit
# of DIMMs and Capacity
  • Up to 256GB ECC RDIMM, in 8 DIMM slots
Hard Drives 4x 3.5" Bays BPN-SAS3-815TQ-N4 SAS3/NVMe Hybrid Backplane
RAID Controller Intel® C612 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10
RAID Levels RAID 0,1,5,10
Power Supply 2x 500W PWS-504P-1R
Optical Drive NONE
Network
  • Single LAN with Intel® X550 10GBase-T Ethernet Controller

    Single LAN with Virtual Machine Device Queues reduce I/O overhead

    Single LAN with Supports 10Base-T, 100BASE-TX, and 1000BASE-T, RJ45 output

    Single LAN with Realtek RTL8201N PHY (dedicated IPMI)
Remote Access
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2400 BMC
Rackmount Rails NONE
Operating System N/A
Power Cord NONE

Condition: Off-lease equipment. Clean and tested by a qualified technician. Barebone unit - NO CPU/NO MEMORY/NO HDDs included. SOLD AS PICTURED.

Any Memory/CPUs or other parts purchased at our store can be added/installed and shipped together at no additional cost.

30-Day Warranty!
