Supermicro CSE-846BE1C-R920B 4U 24-Bay Server Chassis 2x 920W BPN-SAS3-846EL1

Supermicro CSE-846BE1C-R920B SuperChassis 4U 24-Bay Rackmount Server Chassis with 2x 920W SQ (SuperQuiet) PSUs, 24 x 3.5" Front hot-swap SAS/SATA Drive Bays, and 2x 2.5" Rear how-swap SATA Drive Bays

Condition: Off-lease equipment. Clean and tested by a qualified technician. Sold as pictured, no other accessories are included. Rail kit is not included. 24x 3.5" and 2x 2.5" HDD trays and screws are included.

Specifications:

Form Factor:

• Supermicro CSE-846BE1C-R920B 24x 3.5" Drive Bays 4U rackmount chassis
• 4U chassis support for max. motherboard size - EE-ATX (13.68" x 13"), E-ATX (12" x 13"), ATX (12" x 10")

Expansion Slots:

• 7 full-height & full-length expansion slot(s)

Drive Bays:

• 24 x 3.5" hot-swap drive bays, SAS HDD and Enterprise SATA HDD recommended.

  Supermicro BPN-SAS3-846EL1 24-port 4U SAS3 12Gbps single-expander backplane, support up to 24x 3.5-inch SAS3/SATA3 HDD/SSD
• Optional MCP-220-84610-0N SuperMicro Rear Side Dual 2.5 HDD/SSD Kit included

Front Panel:

• Buttons: Power On/Off, System Reset buttons.

  LEDs: 2x Network Activity LEDs, Fan Fail/System Over Heat LED, HDD activity LED, Power Status LED, Unit Identification (UID) LED

System Cooling:

• 3x 8cm hot-swap redundant PWM cooling fans, 2x 80mm rear hot-swap exhaust PWM fans

Power Supply:

• 2x Redundant (1+1) 900WPWS-920P-SQ Redundant Platinum Level power supplies W/PMbus

  High-efficiency - 80 PLUS Platinum Certified
