Supermicro MicroCloud 5039MD8-H8TNR 8-Node Xeon D-2141I 2.2GHz 0GB 3U Server CTO
94926Supermicro MicroCloud 5039MD8-H8TNR 8-Node Xeon D-2141I 2.2GHz 0GB 3U Server CTO
Supermicro MicroCloud SYS-5039MD8-H8TNR 8-Node Xeon D-2141I 2.2GHz 0GB RAM 3U Rackmount Server CTO
Manufacturer: Supermicro
Model: SYS-5039MD8-H8TNR MicroCloud
Part Number: SYS-5039MD8-H8TNR
Condition: Clean off-lease equipment. Fully tested by a qualified technician and guaranteed 100% working. Each node has been individually inspected and configured.
What's Included:
• Supermicro MicroCloud SYS-5039MD8-H8TNR 8-Node 3U Server
• 8x Supermicro X11SDD-8C-F Nodes with Intel Xeon D-2141I 8-Core 2.2GHz CPUs (soldered, one per node)
• 16x Supermicro Black Gen 6.5 Hot-Swap 3.5" HDD Trays (MCP-220-00094-0B)
• 2x 1600W Titanium Level Redundant Power Supplies (PWS-1K68A-1R)
• Rackmount Rail Kit (MCP-290-00057-0N)
Note: No RAM, drives, or OS are included. 2.5" hybrid SATA/NVMe kits are not installed.
30-Day Warranty Included!
Excellent high-density 8-node solution for service providers, hosting companies, edge computing, virtualization clusters, and large-scale enterprise deployments. Run multiple isolated workloads efficiently in just 3U of rack space.
This is a genuine Supermicro MicroCloud SYS-5039MD8-H8TNR 8-Node 3U server. Each of the eight independent nodes features a powerful Intel Xeon D-2141I processor, making this one of the best density/performance options available for modern data centers and cloud environments.
Specifications:
| Product SKUs | SYS-5039MD8-H8TNR (Black) |
|---|---|
| Motherboard (per node) | Super X11SDD-8C-F |
| Processor (per node) | Intel Xeon D-2141I, 8 Cores / 16 Threads, 2.2 GHz, 65W TDP, Socket FCBGA1667 |
| System Memory (per node) | 4x 288-pin DDR4 DIMM slots Up to 512 GB ECC LRDIMM Up to 256 GB ECC RDIMM |
| Memory Type / Speed | 2133MHz ECC DDR4 LRDIMM and RDIMM |
| Network (per node) | Intel i350 Dual GbE LAN (RJ45) |
| Storage (per node) | 2x 3.5" SATA3 bays (2.5" hybrid SATA3/NVMe bays available with optional kits — not included) |
| Expansion (per node) | 1x PCIe 3.0 x16 (Low-profile) 1x Micro-LP PCIe 3.0 x8 2x M.2 (PCIe 3.0 x4, 2280/22110, M-Key) |
| Remote Management | IPMI 2.0 with KVM-over-LAN, Virtual Media (ASPEED AST2500 BMC) |
| Power Supply | 2x 1600W Titanium Level Redundant PSUs (PWS-1K68A-1R) |
| Cooling (per node) | 4x Hot-swap 8cm fans with intelligent fan speed control |
| Chassis | CSE-938NH-R1K68BP 8-Node 3U Rackmount |
| Dimensions (H x W x D) | 5.2" x 15.26" x 23" (132 x 387 x 585 mm) |
| Weight | Net: 62.2 lbs (28.21 kg) |
