Supermicro SYS-1029U-E1CR25M X11DPU 2x Intel Xeon Gold 5120 192GB RAM 1U Server

94242

Supermicro SYS-1029U-E1CR25M X11DPU 2x Intel Xeon Gold 5120 192GB RAM 1U Server

Skip to product information
1 of 3

SUPERMICRO

Regular price $999.99 USD
Regular price Sale price $999.99 USD
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

View full details

Supermicro SYS-1029U-E1CR25M X11DPU 2x Intel Xeon Scalable Gold 5120 2.2GHz (3.2GHz Max Turbo) 14-Core CPUs 192GB RAM 2x 25GbE 1U Rackmount Server with Rail Kit included.

Specifications:

Form Factor 1U Rackmount
Model SUPERMICRO SYS-1029U-E1CR25M - 10 2.5" Bays
Processor(s) 2x Intel SR3GD Xeon Gold 5120 2.2Ghz 14-Core 19.25MB L3 Cache LGA3647 Processor CPU
Memory 192GB PC4-2666V (DDR4-2666MHZ) Registered ECC Memory
# of DIMMs and Capacity 12x 16GB PC4-2666V (DDR4-2666MHZ) DIMMs installed
Hard Drives 10 Hot-swap 2.5" drive bays:
10 SAS3/SATA3 ports via
Expander and AOC;
RAID Controller AOC-S3108L-H8iR-16DD Std LP, 8 internal ports, 12Gb/s per port- Gen3 RAID Controller, 2GB Cache
RAID Levels RAID 0, 1, 5, 6, 10, 50, 60
Power Supply 2x PWS-751P-1R 1U 750W Redundant Platinum Single Output Power Supplies w/Pmbus
Optical Drive NONE
Network 2x 25GbE SFP28 ports via AOC-URN4-M2TS-O (Mellanox ConnectX-4 Lx EN)
Remote Access

Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

ASPEED AST2500 BMC

Rackmount Rails Yes
Operating System N/A
Power Cord None

Condition:Off-lease equipment. Clean and tested by a qualified technician. Rackmount rail kit is included.

30-Day Warranty!
