SuperMicro SYS-2028TP-HTR-SIOM 4-Node X10DRT-PS 2U SuperServer Barebone/CTO
94757SuperMicro SYS-2028TP-HTR-SIOM 4-Node X10DRT-PS 2U SuperServer Barebone/CTO
SuperMicro SYS-2028TP-HTR-SIOM 4-Node X10DRT-PS 2U SuperServer Barebone/CTO
Barebone unit:
- NO CPUs/NO HDDs/NO RAM/NO NETWORK SIOMS
- HDD Trays are included. The rackmount rail kit is not included but can also be purchased separately.
Specifications:
| Form Factor | 2U2U RACKMOUNT |
|---|---|
| Model | SUPERMICRO SYS-2028TP-HTR-SIOM -242.5"Bays |
| Processor(s) | Intel Xeon processor E5-2600 v4/ v3 family (up to 145W TDP) * Dual Socket R3 (LGA 2011) |
| Memory | 2400/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit |
| # of DIMMs and Capacity | 16x 288-pin DDR4 DIMM slots Up to 2TB ECC 3DS LRDIMM, 512 ECC RDIMM |
| Hard Drives | 24 Hot-swap 2.5" SAS/SATA HDD Bays |
| RAID Controller | Intel C612 chipset onboard |
| RAID Levels | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| Power Supply | 2x2000W PWS-2K04A-1R |
| Optical Drive | N/A |
| Network | NOT INCLUDED |
| Remote Access | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC |
| Rackmount Rails | NONE |
| Operating System | N/A |
| Power Cord | No |
Condition:Off-lease equipment. Clean and tested by a qualified technician.
30-Day Warranty!
