Supermicro SYS-2029UZ-TN20R25M 2x Xeon Gold 6140 2.3Ghz 192GB 20x NVMe 2U Server
92253Supermicro SYS-2029UZ-TN20R25M 2x Xeon Gold 6140 2.3Ghz 192GB 20x NVMe 2U Server
Supermicro SYS-2029UZ-TN20R25M 2x Xeon Gold 6140 2.3Ghz 192GB 20x NVMe 2U Server
Supermicro SYS-2029UZ-TN20R25M 2x Xeon Gold Scalable 6140 18-Core 2.3Ghz CPUs 192GB RAM 20x NVMe ports (direct connect) 2U Rackmount Server
Specifications:
| Form Factor | 2U RACKMOUNT |
|---|---|
| Model | SUPERMICRO SYS-2029UZ-TN20R25M - 24x 2.5" Bays |
| Processor(s) | 2x Intel SR3AX Xeon Gold 6140 2.3Ghz 18-Core 24.75MB L3 Cache LGA3647 Processor CPU |
| Memory | 192GB PC4-2666V (DDR4-2666MHZ) Registered ECC Memory |
| # of DIMMs and Capacity | 12x 16GB PC4-2666V (DDR4-2666MHZ) Memory Modules |
| Hard Drives | 24 Hot-swap 2.5" drive bays; 20 NVMe + 4 SATA; 1 M.2 NVMe port, Optional extra M.2 NVMe and SATA3 ports |
| RAID Controller | Intel® C621 chipset |
| RAID Levels | SATA3 (6Gbps); RAID 0, 1, 5, 10 |
| Power Supply | 2x 1600W PWS-1K62A-1R |
| Optical Drive | N/A |
| Network |
2x 25GbE SFP28 ports via AOC-2UR68-m2TS (Mellanox ConnectX-4 Lx EN) 2x 25GbE SFP28 ports |
| Remote Access |
Support for Intelligent Platform Management Interface v.2.0 ASPEED AST2500 BMC |
| Rackmount Rails | Yes/Included |
| Operating System | N/A |
| Power Cord | No/Not included |
Condition: Off-lease equipment. Clean and tested by a qualified technician. Rackmount rail kit and SSD trays/caddies are included.
30-Day Warranty!
