Supermicro SYS-620U-TNR X12DPU-6 Dual Intel Xeon Scalable Silver 4310 12-Core 2.1GHz (3.3GHz Max Turbo Frequency) 128GB RAM PCIe 4.0 12-Bay 3.5" 2U Rackmount Server with Rail Kit Included

Specifications:

Form Factor 2U Rack Mount
Model SUPERMICRO SYS-620U-TNR - 12 3.5" Bays
Processor(s)

2x 3rd Gen Intel Xeon Silver Scalable 4310 12-Core 2.1GHz (3.3GHz Max Turbo Frequency) Processors
Memory 128GB (4x 32GB DIMMs) PC4-3200AA - Registered ECC Memory Installed
# of DIMMs and Capacity 32 DIMM Slots; Up to 8TB DRAM; Up to 8TB Intel Optane Persistent Memory (up to 12TB with DRAM); 3200/2933/2666 ECC DDR4 LRDIMM;RDIMM; Intel Optane Persistent Memory 200 series
Hard Drives
  • None Installed
  • 12x 3.5" hot-swap hybrid NVMe/SATA/SAS drive bays
  • In current configuration 4x Bays (9-11) connected to NVMe ports and 12x Bays  (0-11) to AOC-S3816L-L16iT SAS/SATA HBA
HBA Controller

AOC-S3816L-L16iT HBA with 1x CBL-SAST-1264F-100 and 1x CBL-SAST-1265F-100

  • Broadcom 3816SAS controller, 16internal ports, 12Gb/s per port
  • 2x SlimSAS x8 black (100-Ohm) connector interface
  • Supports up to 122 physical devices with expander
  • Processor at 1.2 GHz
  • Supports 3.0, 6.0 and 12.0 Gb/s SAS data transfer rates and 3.0 & 6.0 Gb SATA
  • Supports MCTP over PCIe
  • UEFI Configuration utility
  • Supports HW Secure Boot
  • OS Support: Windows/Linux
RAID Levels N/A
Power Supply 2x 2000W PWS-2K08A-1R
Optical Drive N/A
Network

2U Ultra Riser with 2-port 10G RJ45 & 2-port 10G SFP+, Intel Carlsville X710-TM4
Remote Access
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

ASPEED AST2600 BMC
Rackmount Rails Yes
Operating System N/A
Power Cord None

Condition: Off-lease equipment. Clean and tested by qualified technician. Rackmount rail kit included.



30-Day Warranty!
